The Craftsman 22 Inch Wheeled Trimmer is a powerful and versatile tool designed for efficient grass and weed trimming. Featuring a robust 675 Series Briggs & Stratton engine, it offers a 22-inch cutting width and adjustable height settings for precise trimming. Ideal for both home and commercial use, this trimmer combines durability with ease of operation, making it a reliable choice for maintaining large outdoor spaces.

1.1 Overview of the Trimmer

The Craftsman 22 Inch Wheeled Trimmer is a high-performance tool designed for efficient cutting of grass and weeds. It features a durable 675 Series Briggs & Stratton engine, providing reliable power for tough trimming tasks. The trimmer boasts a 22-inch cutting width, allowing for quick and precise results. With its adjustable trimming height, users can customize the cut to suit different grass lengths and terrain. The wheeled design enhances mobility, making it ideal for large outdoor spaces. Designed for both residential and commercial use, this trimmer combines strength and versatility, offering a practical solution for maintaining neat and tidy lawns. Its robust construction and user-friendly controls ensure long-lasting performance and ease of operation.

1.2 Key Features and Benefits

The Craftsman 22 Inch Wheeled Trimmer offers several standout features that make it an excellent choice for lawn maintenance. Its 22-inch cutting width ensures efficient trimming, covering more area with fewer passes. The 675 Series Briggs & Stratton engine provides reliable power, capable of handling thick grass and weeds. Adjustable trimming height allows users to customize the cut, while the wheeled design enhances mobility and reduces fatigue. The trimmer is built with durable materials, ensuring long-lasting performance. Additional benefits include a two-year warranty for residential use, covering defects in material and workmanship. Its ergonomic handle and intuitive controls make operation straightforward. Whether for large yards or commercial projects, this trimmer delivers power, precision, and versatility, making it a valuable tool for maintaining a well-manicured lawn.

Safety Precautions

Always read the manual thoroughly before operating the Craftsman 22 Inch Wheeled Trimmer. Wear protective gear, ensure the area is clear of obstacles, and keep children and pets away. Avoid contact with hot engine parts and never operate near open flames or sparks. Properly maintain the trimmer to prevent accidental start-ups or malfunctions. Follow all safety guidelines to ensure safe and effective operation.

2.1 General Safety Rules

Before operating the Craftsman 22 Inch Wheeled Trimmer, read the manual thoroughly and understand all safety guidelines. Always wear protective gear, including gloves, safety glasses, and sturdy footwear. Ensure the area is clear of debris, children, and pets. Avoid operating near open flames, sparks, or flammable materials. Never touch hot engine parts or allow loose clothing to come into contact with moving components. Maintain a firm grip on the handles and stay alert to avoid accidents. Properly maintain the trimmer to prevent malfunctions. Follow all warnings and precautions outlined in the manual to ensure safe and effective operation. Failure to adhere to these rules may result in injury or damage. Always prioritize safety when using the Craftsman Wheeled Trimmer.

2.2 Protective Gear Recommendations

Wearing proper protective gear is essential when operating the Craftsman 22 Inch Wheeled Trimmer. Always wear long pants or heavy-duty work pants to protect your legs from debris. Safety glasses or goggles are mandatory to shield your eyes from flying particles. Additionally, wear sturdy, closed-toe footwear to prevent injuries from accidental blade contact. Gloves are highly recommended to improve grip and reduce vibration fatigue. A long-sleeve shirt can provide extra protection fromcuts and scratches. For added safety, consider wearing a face mask to avoid inhaling dust or debris. Ensure all gear fits properly and does not obstruct movement. By following these recommendations, you can minimize risks and operate the trimmer safely. Always consult the manual for specific guidelines on protective equipment.

2.3 Hazardous Situations to Avoid

When operating the Craftsman 22 Inch Wheeled Trimmer, it is crucial to avoid certain hazardous situations to ensure safe and effective use. Never operate the trimmer on uneven or steep slopes, as this can cause loss of control or tip-over. Avoid trimming in wet or slippery conditions, as this increases the risk of accidents. Do not operate near open flames or sparks, as the trimmer may produce ignition sources. Keep the trimmer away from loose clothing or long hair, which could get entangled in moving parts. Never use the trimmer near children or pets, as they may inadvertently come into contact with the machine. Additionally, avoid trimming in confined spaces where carbon monoxide buildup could occur. Always turn off the engine and allow it to cool before refueling or performing maintenance. By avoiding these hazards, you can significantly reduce the risk of injury or damage.

Assembly and Setup

Begin by carefully unpacking and inventorying all components. Attach the handle and wheels according to the manual’s instructions. Adjust the trimming height to your preference for optimal performance.

3.1 Unpacking and Inventory

Start by carefully unpacking the Craftsman 22 Inch Wheeled Trimmer from its box. Ensure all components are included and undamaged. The package should contain the trimmer base, handle, wheels, engine, and cutting head, along with mounting hardware and an owner’s manual. Verify the presence of all parts by cross-referencing the manual’s inventory list. If any items are missing or damaged, contact Sears customer support immediately. Familiarize yourself with the trimmer’s components, such as the Briggs & Stratton engine, adjustable handle, and cutting string system. Before proceeding with assembly, double-check that all parts are accounted for to avoid delays. Properly unpacking and inventorying ensures a smooth setup process and prevents potential issues during operation.

3.2 Attaching the Handle and Wheels

Begin by attaching the handle to the trimmer base using the provided bolts. Ensure the handle is securely tightened to maintain stability. Next, install the wheels by aligning the wheel axles with the designated mounts on the trimmer base. Use the included nuts and bolts to fasten them in place. Tighten all connections firmly to prevent loosening during use. Adjust the handle height to a comfortable position for easy maneuverability. Once the handle and wheels are securely attached, double-check all connections to ensure they are tight and properly aligned. This step is crucial for maintaining balance and control while operating the trimmer. Refer to the owner’s manual for specific diagrams or instructions if needed. Proper assembly ensures safe and efficient operation of the Craftsman 22 Inch Wheeled Trimmer.

3.3 Adjusting the Trimming Height

To adjust the trimming height on your Craftsman 22 Inch Wheeled Trimmer, locate the height adjustment lever or knob on the trimmer head. Depending on your model, this may involve pushing a locking tab or turning a dial. Once released, move the trimmer head up or down to your desired cutting height. Most models offer a range of 1.5 to 4 inches for precise control. For optimal performance, set the height to maintain the recommended 2-3 inches for most grass types. After adjusting, secure the locking mechanism to ensure stability. Always refer to your owner’s manual for specific instructions tailored to your trimmer model. Proper height adjustment ensures even cutting and protects your lawn from damage. This feature makes the trimmer versatile for various grass and weed conditions. Adjusting the height is a simple process that enhances your trimming experience.

Operating the Trimmer

The Craftsman 22 Inch Wheeled Trimmer is designed for efficient operation, featuring a powerful engine and a 22-inch cutting width. It is easy to maneuver, allowing for precise control over trimming operations. The adjustable height and throttle control ensure optimal performance for various grass and weed conditions. Always maintain the recommended cutting height to avoid damaging the lawn or the trimmer. Regularly check and maintain the trimmer string and engine to ensure smooth operation. Follow the manual instructions for starting, stopping, and adjusting settings to maximize efficiency and safety;

4.1 Starting the Engine

To start the engine of the Craftsman 22 Inch Wheeled Trimmer, begin by priming the engine. Locate the primer bulb on the carburetor and press it 2-3 times until it becomes firm. Next, move the choke lever to the “start” or “choke” position. Grip the starter handle firmly and pull the cord slowly until resistance is felt, then pull sharply to engage the engine. Once the engine starts, gradually move the choke lever to the “run” position to allow the engine to warm up. Ensure the trimmer is on level ground and the cutting head is clear of debris before starting. Always wear protective gear, including gloves and safety glasses, when operating the trimmer. Refer to the manual for specific starting procedures and safety guidelines to ensure proper operation and longevity of the engine.

4.2 Using the Throttle and Drive Control

The Craftsman 22 Inch Wheeled Trimmer features a throttle and drive control system designed for precise operation. To use the throttle, grip the handle firmly and squeeze the throttle lever gradually to increase engine speed. The drive control bar, located on the handle, allows you to engage and disengage the cutting head. Always start with a slow throttle setting and adjust as needed for optimal cutting performance. For better maneuverability, use the drive control to power the wheels while trimming large areas. When operating on uneven terrain, reduce throttle speed to maintain stability. Ensure the trimmer is moving forward before engaging the drive control to avoid accidental starts. Keep a firm grip on the handle at all times, especially when navigating slopes or tight spaces. Proper use of these controls ensures efficient trimming and safe operation of the trimmer.

4.3 Tips for Effective Trimming

For optimal results with the Craftsman 22 Inch Wheeled Trimmer, maintain the correct cutting height based on grass and weed thickness. Keep the trimming head parallel to the ground to ensure even cuts. Regularly inspect and replace the trimming string or blade to prevent poor performance. Clear debris from the trimming path before starting to avoid jams. Work in small, manageable sections, overlapping slightly to ensure full coverage. Use the throttle to adjust speed according to grass density, and engage the drive control for smoother operation on large areas. Avoid trimming over steep slopes or uneven terrain to maintain stability. Lubricate moving parts periodically to keep the trimmer running smoothly. By following these tips, you can achieve professional-grade results while extending the lifespan of your trimmer.

Maintenance and Care

Regularly check and replace the air filter, and ensure proper engine oil levels using SAE 30 oil. Inspect and maintain the trimmer string or blade, and clean debris from the underside to ensure optimal performance.

5.1 Engine Oil Requirements

The Craftsman 22 Inch Wheeled Trimmer requires the use of SAE 30 engine oil for optimal performance. The engine oil capacity is approximately 15 to 22 ounces, depending on the model. It is essential to refer to the engine owner’s manual for specific oil quantity recommendations, especially for cold-weather starting. Regular oil checks are crucial to ensure the engine runs smoothly and to prevent damage. Always use high-quality oil that meets the specifications outlined in the manual. Proper lubrication is vital for maintaining the longevity and efficiency of the trimmer’s engine. Additionally, checking the oil level before each use ensures consistent performance and helps prevent overheating or mechanical failure. By adhering to these guidelines, users can maintain their trimmer’s engine in excellent condition for years of reliable service.

5.2 Air Filter Cleaning and Replacement

Regular maintenance of the air filter is essential for the optimal performance of the Craftsman 22 Inch Wheeled Trimmer. The air filter should be cleaned or replaced as specified in the manual to ensure proper engine operation. Start by turning off the engine and allowing it to cool. Locate the air filter housing, typically near the engine, and remove the cover. Gently pull out the air filter and inspect it for dirt or debris. If it is dirty, tap it lightly to remove loose particles, or clean it with compressed air if recommended. If the filter is damaged or excessively worn, replace it with a new one. Reinstall the filter and cover, ensuring a secure fit to prevent dust and debris from entering the engine. Cleaning or replacing the air filter regularly helps improve engine efficiency, prevents overheating, and extends the lifespan of the trimmer. Always follow the manufacturer’s guidelines for replacement intervals.

5.3 Trimmer String Replacement

Replacing the trimmer string on your Craftsman 22 Inch Wheeled Trimmer is a straightforward process that ensures optimal cutting performance. Begin by turning off the engine and allowing the machine to cool. Locate the string spool, typically found under the cutting deck, and remove it by pulling straight out or according to the manual’s instructions. Cut a new piece of trimmer string to the recommended length, usually around 18.75 inches, and ensure it matches the specified diameter (0.155 inches). Wind the string neatly around the spool, leaving a small portion to feed through the guide hole. Reinstall the spool and test the trimmer to ensure proper operation. Regularly inspect and replace the string to maintain cutting efficiency and prevent damage to the trimmer head. Always use high-quality string designed for your model to ensure reliability and performance.

Troubleshooting Common Issues

This section helps identify and resolve common problems with the Craftsman 22 Inch Wheeled Trimmer, such as engine issues, poor cutting performance, or excessive vibration. Regular maintenance and inspection are key to preventing these issues and ensuring smooth operation. Always refer to the manual for detailed diagnostic steps and solutions.

6.1 Engine Not Starting

If the engine fails to start, check the fuel level and ensure it is fresh and correctly mixed with oil if required. Verify the oil level is within the recommended range using SAE 30 engine oil. A clogged air filter or blocked fuel line can also prevent the engine from starting. Inspect the spark plug for wear or fouling and replace it if necessary. Ensure the choke is properly adjusted and the throttle is in the correct starting position. If issues persist, consult the manual for specific troubleshooting steps or contact customer support for assistance. Regular maintenance, such as cleaning the air filter and checking fuel lines, can help prevent starting problems. Always follow safety guidelines when attempting repairs.

6.2 Poor Cutting Performance

Poor cutting performance can result from incorrect trimmer string length or damaged lines. Ensure the string is within the recommended 18.75-inch length with a 0.155-inch diameter. Worn or frayed lines should be replaced. Check for proper string tension, as loose lines may not cut effectively. Debris accumulation around the trimmer head can also impede performance; clean it regularly. If the engine lacks power, inspect the air filter for blockages and clean or replace it as needed. Low engine oil levels or incorrect oil type can reduce efficiency, so verify the oil level and use SAE 30 engine oil. Adjust the trimming height to suit the grass type, as cutting too low or high can reduce effectiveness. For optimal results, maintain the trimmer head at the correct angle and avoid overloading the engine. Regular maintenance and proper setup are key to ensuring consistent cutting performance. Always refer to the manual for specific guidance.

6.3 Vibration or Noise Problems

Vibration or excessive noise in the Craftsman 22 Inch Wheeled Trimmer may indicate improper maintenance or worn components; Check for loose bolts or screws, especially around the handle and wheels, and tighten them as needed. An unbalanced trimmer head can cause vibration; ensure the cutting string is evenly distributed and not damaged. Inspect the drive belt for wear or misalignment and replace it if necessary. Noise could also result from a worn or damaged pulley system; lubricate moving parts and replace any faulty components. If the engine is overheating, allow it to cool before resuming use. Regularly servicing the engine, including oil changes and air filter cleaning, can prevent vibration and noise issues. Always refer to the manual for specific diagnostic steps and repair guidelines to maintain optimal performance and reduce operational disruptions. Proper maintenance ensures smoother operation and extends the trimmer’s lifespan.

Warranty and Support

The Craftsman 22 Inch Wheeled Trimmer is backed by a two-year limited warranty covering defects in material and workmanship when properly maintained. Sears offers dedicated customer support for repairs, replacements, and service inquiries, ensuring reliable assistance for any issues. Regular maintenance as per the manual is required to uphold warranty terms. For detailed information or assistance, contact Sears through their official website or customer service channels. This warranty does not apply to commercial or rental use, providing peace of mind for residential users. Proper maintenance and adherence to guidelines ensure optimal performance and warranty coverage.

7.1 Warranty Terms and Conditions

The Craftsman 22 Inch Wheeled Trimmer is covered by a limited two-year warranty from the date of purchase. This warranty applies to defects in material and workmanship when the trimmer is properly maintained, lubricated, and serviced according to the owner’s manual. Sears, the manufacturer, agrees to repair or replace defective parts free of charge during this period. However, the warranty does not cover damage resulting from misuse, neglect, or commercial/rental use. Regular maintenance, as outlined in the manual, is required to maintain warranty coverage. The warranty is valid for residential use only. For warranty claims, contact Sears customer support with proof of purchase and a detailed description of the issue. The model and serial numbers, located on the rear decal, must be provided for verification. Proper adherence to warranty terms ensures optimal performance and extends the lifespan of the trimmer.

7.2 Contacting Customer Support

For assistance with the Craftsman 22 Inch Wheeled Trimmer, customers can contact Sears customer support through various channels. Visit the official Craftsman website at www.craftsman.com for support options, including live chat, email, and phone support. Additionally, Sears customer service can be reached by phone or through their website. When contacting support, have the model number (e.g., 917.773420) and serial number readily available, as these are required for efficient service. For warranty-related inquiries or repair requests, provide details of the issue and proof of purchase. Sears also offers online resources, including FAQs and repair parts information, to help troubleshoot common issues. Ensure to follow the guidelines provided in the manual for proper communication and resolution. Prompt and accurate information ensures quicker assistance from the support team.

7.3 Repair and Service Options

For repair and service needs, the Craftsman 22 Inch Wheeled Trimmer is supported by Sears’ extensive network of authorized service centers. Customers can visit the Sears PartsDirect website to order genuine parts, such as engine components, trimmer strings, or other accessories. Sears also offers in-store or on-site repair services for convenience. For warranty-covered repairs, ensure the trimmer is registered and maintained according to the manual’s guidelines. Contact Sears customer support to locate the nearest authorized service provider or to schedule a repair. Additionally, Sears provides online resources, such as repair manuals and troubleshooting guides, to help users address minor issues independently. Always use genuine Craftsman parts to maintain warranty validity and ensure optimal performance. Sears’ repair services are designed to restore your trimmer to its original condition efficiently.

Additional Resources

Access Frequently Asked Questions, online manuals, and parts information for the Craftsman 22 Inch Wheeled Trimmer on the official Sears website or through authorized dealers.

8.1 Frequently Asked Questions

Here are some common questions about the Craftsman 22 Inch Wheeled Trimmer:

What type of engine oil is recommended? Use SAE 30 engine oil for optimal performance.

How do I adjust the trimming height? Push the locking plate tab and move the trimmer head up or down.

What is the cutting width? The trimmer features a 22-inch cutting path for efficient trimming.

Can it be used commercially? Yes, but the warranty may vary for commercial use.

Where can I find replacement parts? Visit Sears or authorized dealers for genuine parts.

How often should I clean the air filter? Clean or replace the air filter regularly to ensure proper engine performance.

What is the recommended cutting height? The average yard requires a cutting height of 2 inches.

These FAQs provide quick solutions and tips for maintaining and operating your trimmer effectively.

8.2 Online Manuals and Guides

Accessing the Craftsman 22 Inch Wheeled Trimmer manual is straightforward, with multiple online resources available:

– Visit the official Craftsman website or Sears PartsDirect to download the PDF manual for models like 917.773420 or 917.773740.

– The manual includes detailed instructions for safety, assembly, operation, and maintenance.

– Additional guides on troubleshooting and warranty information are also available.

– For model-specific instructions, refer to the Craftsman CMGT232501 manual, which covers the 22-inch wheeled trimmer with a Briggs & Stratton engine.

– Online forums and repair websites offer tips and diagrams for parts replacement and service.

These resources ensure you can operate and maintain your trimmer effectively, whether for home or commercial use.

8.3 Parts and Accessories Information

For the Craftsman 22 Inch Wheeled Trimmer, a variety of parts and accessories are available to maintain and enhance its performance:

– Genuine Craftsman parts, such as Briggs & Stratton engine components, trimmer string, and replacement cutting heads, can be purchased from Sears PartsDirect or authorized dealers.

– Accessories like wheel kits, air filters, and oil kits are also available to keep your trimmer in optimal condition.

– Refer to your model-specific manual (e.g., 917.773420 or 917.773740) for a detailed parts list and compatibility information.

– Online retailers and Craftsman’s official website provide easy access to these items, ensuring your trimmer remains functional and efficient for years to come.
